New Products: Screens: S130
The McCloskey S130 represents the most advanced 14'x5' portable vibratory screening plant in porduction today. Combining this class leading screening with the McCloskey High Energy Screen technology ensures that no other similar size screener can compare.
The S130 is a highly effective screener that offers all the class leading features associated with the McCloskey S-Range, such as the High Energy Screenbox and user friendly features. The S130 can be used across a wide range of applications from aggregate, to coal, crusher circuits, wood chip, and performs extremely well in fine sand screening, on which it has excelled and stunned customers worldwide with its production capacities.
The S130's unique size is designed to meet demands of operators who require significantly more screening capacity than a 10' or 11' screenbox, but may not require the full capacity of a 20' plant.
The S130's production capabilities have been proved in a number of application demonstrations where the S130 has matched, or in some cases outperformed in productivity against the 'so called' larger competitor models, in the same material, with the same screen mesh sizes.
| Specifications | |
| Powerunit: | 100 HP |
| Screenbox - top deck: | 4.270m x 1.524m (14' x 5') |
| Screenbox - bottom deck: | 3.660m x 1.524m (12' x 5') |
| Length - transport all models: | 15.09m (49' - 6") |
| Width - transport all models: | 2.90m (9' - 6") |
| Height - transport 2 deck track: | 3.40m (11' -2") |
| Height - transport 2 deck wheel: | 3.68m (12' - 1") |
| Weight - 2 deck track: | 27,200kgs (59,965 lbs) - est |
| Weight - 2 deck wheel: | 23,000kgs (50,706 lbs) - est |
